FAVO HD14 CLASS TD AMPLIFIER, 2 CHANNELS, 13000W

PRODUCT DESCRIPTION:

• Two-channel with an unprecedented power of 2x6500W and concert specifications.
• Professional components, Neutrik connectors, design and low weight allow it to be used for the toughest tasks.
• 3-year warranty.
• HD and HDQ amplifiers are the primary drive for NAW Performance Audio systems.

KEY FEATURES:

• huge reserve of power
• built-in voltage peak limiter with adjustable parameters
• professional Neutrik connectors
• possibility of bridging channels
• air drawn in from the front and expelled from the back of the amplifier
• low weight 12kg
• rack height 2U

The HD14, HDQ10, and HDQ6 amplifiers stand out from the competition thanks to their sound quality and reliability, which we achieved thanks to, among other things:

• the size and material used to make the radiators - suitably large, made of pure copper, with an optimal shape, ensure excellent heat dissipation,
• the quality of the transistors, capacitors and other electronic components used
• original Neutrik connectors,
• size and quality of fans.

TECHNICAL SPECIFICATIONS:

• Frequency range : 20hz-20kHz
• Power: 2x2400W@8Ohm, 2x4800W@4Ohm, 2x6500W@2Ohm, 1x9600W@8Ohm Bridge, 1x13000W@4Ohm Bridge
• Total harmonic distortion (20hz-20khz): <0.1%
• Damping factor (20-500hz @8ohm): > 500
• Crosstalk (@1kHz): >70dB
• Voltage Peak Limiter: Hard/Soft operating modes adjustable from 54V to 195V
• Voltage gain: 23dB to 44dB (in 3db steps)
• Input impedance: 20kOhm
• Sensitivity (nominal power 26/32/38dB gain): 5.9/2.9/1.5V
• Signal to noise ratio (20hz-20khz): 112dB
• AC power required:

  • operating voltage (50hz-60Hz): 130V-265V AC
  • 1/8 nominal power (@230V min. z): 16A
• Dimensions (wxhxd): 483x88.9x400 mm
• Weight (net): 12kg
• Security :
  • soft start,
  • overloaded power supply,
  • mains overvoltage
