FAVO HDQ10 Class TD amplifier, 4 channels, 10000W

PRODUCT DESCRIPTION:

• Four-channel, lightweight, high-power, 4x2500W concert-grade amplifier.
• Professional components, connectors, design and low weight allow it to be used for the toughest tasks.
• 3-year warranty.
• HD and HDQ amplifiers are the primary drive for NAW systems.

KEY FEATURES:

• huge reserve of power
• built-in voltage peak limiter with adjustable parameters
• professional Neutrik connectors
• possibility of bridging channels
• air drawn in from the front and expelled from the back of the amplifier
• low weight 12.8 kg
• rack height 2U

The HD14, HDQ10, and HDQ6 amplifiers stand out from the competition thanks to their sound quality and reliability, which we achieved thanks to, among other things:

• the size and material used to make the radiators - suitably large, made of pure copper, with an optimal shape, ensure excellent heat dissipation,
• the quality of the transistors, capacitors and other electronic components used
• original Neutrik connectors,
• size and quality of fans

TECHNICAL SPECIFICATIONS:

• Frequency range: 20hz-20k Hz
• Power: 4x1300W@8Ohm, 4x2200W@4Ohm, 4x2500W@2Ohm, 2x4400W@8Ohm Bridge, 2x5000W@4Ohm Bridge
• Total harmonic distortion (20Hz-20kHz): <0.1%
• Damping factor (20-500Hz @8Ohm): > 500
• Crosstalk (@1kHz): >70db
• Voltage Peak Limiter: Hard/Soft operating modes adjustable from 38V to 150V
• Voltage gain: 23dB to 44dB (in 3dB steps)
• Input impedance: 20kOhm
• Sensitivity (rated power 26/32/38dB gain): 4.9/2.5/1.2V
• Signal to noise ratio (20Hz-20kHz): 1 12dB
• AC power required:

  • operating voltage (50Hz-60Hz): 130V-265V AC
  • 1/8 nominal power (@230V min. Z): 13A
• Dimensions (WxHxD): 483x88.9x400 mm
• Weight (net): 12.8 kg
• Security :
  • soft start,
  • power supply overload,
  • short circuit protection.
