FAVO HDQ6 CLASS TD AMPLIFIER, 4 CHANNELS, 6000W

PRODUCT DESCRIPTION:

• Four-channel, lightweight, high-power, 4x1500W concert-grade amplifier.
• Professional components, connectors, design and low weight allow it to be used for the toughest tasks.
• 3-year warranty.
• HD and HDQ amplifiers are the primary drive for NAW Performance Audio systems.

KEY FEATURES:

• huge reserve of power
• built-in voltage peak limiter with adjustable parameters
• professional Neutrik connectors
• possibility of bridging channels
• air drawn in from the front and expelled from the back of the amplifier
• low weight 13kg
• rack height 2U

The HDQ6 amplifiers stand out from the competition primarily for their sound quality and reliability, which we achieved thanks to, among other things:

• the size and material used to make the radiators - suitably large, made of pure copper, with an optimal shape, ensure excellent heat dissipation,
• the quality of the transistors, capacitors and other electronic components used
• original Neutrik connectors,
• size and quality of fans

TECHNICAL SPECIFICATIONS:

• Frequency range: 20hz-20kHz
• Power: 4x650W@8Ohm, 4x1300W@4Ohm, 4x1500W@2Ohm, 2x2600W@8Ohm Bridge, 2x3000W@4Ohm Bridge
• Total harmonic distortion (20Hz-20kHz): <0.1%
• Damping factor (20-500Hz @8Ohm): > 500
• Crosstalk (@1kHz): >70db
• Voltage Peak Limiter: Hard/Soft operating modes adjustable from 38V to 101V
• Voltage gain: 23dB to 44dB (in 3dB steps)
• Input impedance: 20kOhm
• Sensitivity (rated power 26/32/38dB gain): 3.5/1.8/0.9V
• Signal to noise ratio (20Hz-20kHz): 1 12dB
• AC power required:

  • operating voltage (50Hz-60Hz): 130V-265V AC
  • 1/8 nominal power (@230V min. Z): 12A
• Dimensions (WxHxD): 483x88.9x400 mm
• Weight (net): 12.8 kg
• Security :
  • soft start,
  • power supply overload,
  • short circuit protection.
